ENGENIUS Ecs1008p Cloud Managed Gigabit 55w 8 Port Poe Switch
Redcorp# Q4342213
Article# ECS1008P
Ecs1008p Cloud Managed Gigabit 55w 8 Port Poe Switch
Other recommendations for your business
EnGenius Cloud Managed Layer 2+ Switch ECS1008P features 8 Gigabit PoE ports, 55W PoE budget. Its enterprise-class features optimize network efficiency and offer robust security with Voice-VLAN support. The switch also extends PoE Ethernet cable deployment range up to 250 meters, auto-reboots PoE power for failed camera, and provides a steady supply of PoE power during switch upgrades. Ideal for cost-conscious SMBs.
Specs
Management features
Switch type
Managed
Switch layer
L2
Quality of Service (QoS) support
Yes
Web-based management
Yes
ARP inspection
Yes
Configuring Location Settings (CLI)
Yes
System event log
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity
8
Network
Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support
No
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Full duplex
Yes
Flow control support
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Spanning tree protocol
Yes
VLAN support
Yes
Virtual LAN features
Port-based VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Data transmission
Switching capacity
16 Gbit/s
MAC address table
8000 entries
Static route
Yes
Number of static routes
63
Number of IP interfaces
20
Jumbo frames support
Yes
Jumbo frames
9000
Security
DHCP features
DHCP relay, DHCP snooping
Access Control List (ACL)
Yes
IGMP snooping
Yes
Security algorithms
802.1x RADIUS, SSH, SSL/TLS
Authentication
Port-based authentication
Authentication type
IEEE 802.1x, RADIUS
Multicast features
Multicast support
Yes
Multicast features
Multicast forwarding
Number of multicast groups filtered
256
Multicast Listener Discovery (MLD) snooping
v1
Protocols
Management protocols
SNMP v1/v2c/v3
Design
Rack mounting
No
Product colour
Black
LED indicators
Yes
Wall mountable
Yes
Performance
Internal memory
256 MB
Flash memory
32 MB
Firmware upgradeable
Yes
Power
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
8
Total Power over Ethernet (PoE) budget
55 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
240 mm
Depth
105 mm
Height
27 mm
Weight
1.5 kg
Packaging content
Cables included
AC
Quick start guide
Yes
User guide
Yes
Logistics data
Harmonized System (HS) code
85176990
