EATON CORPORATION Switched G4 Rack PDU, 0U, 22.5U, IEC-60309 input, 3m cord, 3ph, 11kW, 16A, 415/240V, 24 outlets (12)C13, (12)C39
Redcorp# N4836791
Article# EVSWF316A
Switched G4 Rack PDU, 0U, 22.5U, IEC-60309 input, 3m cord, 3ph, 11kW, 16A, 415/240V, 24 outlets (12)C13, (12)C39
Other recommendations for your business
Specs
Design
PDU types
Switched
Type
Three-phase
Rack capacity
22.5U
Mounting
Vertical
Housing material
Aluminium
Product colour
Black
Display
LCD
Ports & interfaces
AC outlets quantity
24 AC outlet(s)
Power plug
IEC 60309
AC outlet types
C39 coupler, C13 coupler
Ethernet LAN (RJ-45) ports
4
USB ports quantity
2
Features
Colour-coded outlets
Yes
Cable length
3 m
Security algorithms
SNMP
Management features
Supported network protocols
HTTPS
Power
Nominal input voltage
240/415 V
AC input frequency
50/60 Hz
Maximum current
16 A
Maximum power
11000 W
Operational conditions
Operating temperature (T-T)
0 - 60 °C
Weight & dimensions
Width
52 mm
Depth
53 mm
Height
1000 mm
Weight
3.01 kg
Packaging content
Packaging content
Rack PDU
Rack mounting accessories
Quickstart guide
Safety Instructions
