SHUTTLE COMPUTER Barebone - XPC all-in-one X50V9U3 - 15.6in Touchscreen - i3 1315U - Max. 2x 32 GB DDR5-5200 - 2x M.2 2280M - White
Redcorp# 88702904
Article# X50V9U3 WHITE
Barebone - XPC all-in-one X50V9U3 - 15.6in Touchscreen - i3 1315U - Max. 2x 32 GB DDR5-5200 - 2x M.2 2280M - White
Other recommendations for your business
The Shuttle XPC all-in-one X50V9U3 is the latest addition to the X50 Series and is powered by a Gen12/13 Intel ULV processor. The modern processor architecture helps improve on power consumption and computing power. The existing WLAN function can optionally be supplemented with a 4G/5G function with up to 4 antennas. Thanks to its passive heatpipe cooling, the system is virtually noiseless, maintenance-free and approved for 24/7 nonstop operation. Particularly suitable for vertical applications is the arrangement of connectors at the bottom and the IP54 compliant front panel which is dust-protected and protected from splashing of water.
Specs
Processor
Processor manufacturer
Intel
Processor family
Intel® Core™ i3
Processor generation
Intel Core i3-13xxx
Processor model
i3-1315U
Processor cores
6
Processor threads
8
Processor boost frequency
4.5 GHz
Performance cores
2
Efficient cores
4
Performance-core Max Turbo Frequency
4.5 GHz
Efficient-core Max Turbo Frequency
3.3 GHz
Built-in processor
Yes
Processor cache
10 MB
Memory
Memory slots type
SO-DIMM
Number of memory slots
2
Maximum internal memory
64 GB
Supported memory clock speeds
5200 MHz
Supported memory types
DDR5-SDRAM
Memory channels
Dual-channel
Memory voltage
1.1 V
ECC
No
Non-ECC
Yes
Storage
Supported storage drive types
HDD & SSD
Storage drive sizes supported
2.5,M.2
Storage drive interface
PCI Express, Serial ATA III
NVMe
Yes
Number of storage drives supported
3
Graphics
On-board graphics card
Yes
Graphics card family
Intel
On-board graphics card model
Intel® UHD Graphics
Display
Display diagonal
39.6 cm (15.6")
Display resolution
1366 x 768 pixels
Touchscreen
Yes
HD type
HD
Aspect ratio
16:9
Display brightness
220 cd/m²
Audio
Built-in speaker(s)
Yes
Number of speakers
2
RMS rated power
2 W
Network
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN controller model
Realtek RTL8821CE
Ethernet LAN
Yes
Wi-Fi
Yes
LAN controller
Intel® I219
Bluetooth
Yes
Bluetooth version
4.2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
HDMI ports quantity
1
HDMI version
2.0b
VGA (D-Sub) ports quantity
1
Microphone in
Yes
Headphone outputs
1
Ethernet LAN (RJ-45) ports
1
DC-in jack
Yes
Design
Chassis type
All-in-One
Product colour
White
Cooling type
Passive
On/off switch
Yes
LED indicators
HDD, Power
Cable lock slot
Yes
Cable lock slot type
Kensington
VESA mounting
Yes
Panel mounting interface
100 x 100 mm
Product type
All-in-One PC barebone
Performance
Motherboard chipset
Intel SoC
Number of processors supported
1
BIOS type
UEFI AMI
Built-in camera
Yes
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Audio chip
Realtek ALC888S
Technical details
Compliance certificates
BSMI, CB, CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, VCCI
Logistics data
Harmonized System (HS) code
84714100
Software
Windows operating systems supported
Windows 10, Windows 11
Linux operating systems supported
Yes
Sustainability
Sustainability certificates
ENERGY STAR
Power
Power supply type
External AC adapter
Power supply
90 W
Number of power supply units
1
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
AC adapter output voltage
19 V
AC adapter output current
4.74 A
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 90%
Weight & dimensions
Width
391 mm
Depth
42 mm
Height
327 mm
Weight
3.5 kg
Package weight
4.2 kg
Packaging content
Power cord included
Yes
AC adapter included
Yes
Quick start guide
Yes
Drivers included
Yes
